GPU Architecture |
Blackwell 2.0 |
CUDA / Shading Units |
8960 cores |
Memory Size |
16 GB |
Memory Type |
GDDR7 |
Memory Interface |
256-bit |
Memory Speed |
28 Gbps effective |
Bandwidth |
896.0 GB/s |
Boost Clock (Default Mode) |
≈ 2452 MHz |
Boost Clock (OC Mode) |
≈ 2482-2588 MHz |
Base Clock |
≈ 2295 MHz |
Bus / Interface |
PCI Express 5.0 ×16 |
Display Outputs |
2 × HDMI 2.1b, 3 × DisplayPort 2.1b |
Maximum Digital Resolution |
7680 × 4320 (8K) |
Slots |
3.125-slot width |
Dimensions (L × W × H) |
329 × 140 × 62.5 mm |
Power Connector |
1 × 16-pin |
Recommended PSU |
850 W |
TDP / Power Draw |
≈ 300 W |
Weight |
≈ 1.62 kg |
Features |
Aura Sync ARGB, dual-ball bearing Axial-tech fans, MaxContact GPU thermal pad, military-grade components |
Outputs Supported |
4 displays maximum, HDCP 2.3 support |
