| GPU |
NVIDIA GeForce RTX 5060 (Blackwell Architecture) |
| CUDA Cores |
3,840 |
| Base Clock |
2,280 MHz |
| Boost Clock |
2,580 MHz |
| Memory |
8 GB GDDR7, 128-bit bus |
| Memory Speed / Bandwidth |
28 Gbps / 448 GB/s |
| Interface |
PCI-Express 5.0 ×8 |
| Display Outputs |
3 × DisplayPort 2.1b, 1 × HDMI 2.1b |
| Resolution Support |
Up to 4K @480 Hz or 8K @165 Hz with DSC |
| Power Connector |
1 × 8-pin PCIe |
| TDP |
145 W |
| Cooling Design |
Dual-fan compact 2-slot setup (~280 × 120 × 40 mm) |
| APIs & Technology Support |
DirectX 12 Ultimate, Vulkan 1.4, OpenGL 4.6, CUDA Capability 12.0, AV1 Encode/Decode, DLSS 4 (Multi-Frame Generation), Reflex 2, NVIDIA Studio, RTX Neural Shaders |
| Recommended System Power |
550 W |
| OS Support |
Windows 10/11 (64-bit), Linux |
