GPU |
NVIDIA GeForce RTX 5080 (Blackwell architecture) |
CUDA Cores |
10,752 |
Base Clock |
2.30 GHz |
Boost Clock |
Up to 2.78 GHz |
Memory |
16 GB GDDR7, 256-bit, 30 Gbps (~960 GB/s) |
Interface |
PCI Express 5.0 ×16 |
Display Outputs |
3 × DisplayPort 2.1b, 1 × HDMI 2.1b |
Maximum Resolution |
Up to 8K (7680 × 4320) or 4K @480 Hz with DSC |
Power Connector |
1 × 16-pin PCIe (12V-2×8 or adapter) |
Board Power (TDP) |
360 W |
Recommended PSU |
850 W |
Card Size & Slot Width |
~328 × 138 × 60 mm; 3-slot |
Cooling & Features |
Triple-fan open-air design with ARGB lighting (Epic-X RGB), metal backplate |
Supported APIs & Technologies |
DirectX 12 Ultimate, DLSS 4 with Multi-Frame Generation, Reflex 2, 4th-Gen RT Cores, 5th-Gen Tensor Cores, NVIDIA Studio |
Max Displays Supported |
4 |
