GPU |
NVIDIA GeForce RTX 5060 (Blackwell architecture) |
CUDA Cores |
3,840 |
Extreme Clock (MSI Center) |
Up to 2,535 MHz |
Boost Clock |
Up to 2,527 MHz |
Memory |
8 GB GDDR7, 128-bit |
Memory Speed / Bandwidth |
28 Gbps (~448 GB/s) |
PCIe Interface |
PCIe 5.0 ×16 (operating at ×8) |
Display Outputs |
3 × DisplayPort 2.1b, 1 × HDMI 2.1b |
Max Resolution |
Up to 7680 × 4320 (8K) |
Cooling Design |
Dual TORX Fan 5.0, Zero Frozr (0 dB idle), Heat Pipes, Reinforcing Backplate with exhaust vent |
Power Connector |
1 × 8-pin PCIe |
Power Consumption |
~145 W |
Recommended PSU |
550 W |
Card Dimensions |
197 × 120 × 40 mm (2.5-slot design) |
API & Feature Support |
DirectX 12 Ultimate, OpenGL 4.6, NVIDIA DLSS 4, Reflex 2, G-SYNC, 4th-Gen RT cores, 5th-Gen Tensor cores, NVIDIA Studio, NVENC/NVDEC, MSI Center & Afterburner |
OS Support |
Windows 10/11 (64-bit) |
